General Information
| Cap-Base |
G10Q [ G10q]
|
| Life to 50% Failures (Nom) |
13000 h
|
| LSF 2000 h Rated |
98 %
|
| LSF 4000 h Rated |
77 %
|
| LSF 6000 h Rated |
60 %
|
| LSF 8000 h Rated |
45 %
|
| Flux measurement reference |
Sphere
|
Light Technical
| Color Code |
865 [ CCT of 6500K]
|
| Luminous Flux (Nom) |
1250 lm
|
| Luminous Flux (Rated) (Nom) |
1250 lm
|
| Color Designation |
Cool Daylight
|
| Chromaticity Coordinate X (Nom) |
0.313
|
| Chromaticity Coordinate Y (Nom) |
0.337
|
| Correlated Color Temperature (Nom) |
6500 K
|
| Luminous Efficacy (rated) (Nom) |
57 lm/W
|
| Color Rendering Index (Nom) |
80
|
| LLMF 2000 h Rated |
80 %
|
| LLMF 4000 h Rated |
74 %
|
| LLMF 6000 h Rated |
70 %
|
| LLMF 8000 h Rated |
67 %
|
Operating and Electrical
| Power (Nom) |
22.2 W
|
| Lamp Current (Nom) |
0.400 A
|
| Voltage (Nom) |
62 V
|
Temperature
| Design Temperature (Nom) |
25 °C
|
Controls and Dimming
| Dimmable |
Yes
|
Mechanical and Housing
| Bulb Shape |
C-T9 [ C-T9 29 mm]
|
Approval and Application
| Energy Efficiency Class |
G
|
| Mercury (Hg) Content (Max) |
8 mg
|
| Mercury (Hg) Content (Nom) |
8 mg
|
| Energy Consumption kWh/1000 h |
23 kWh
|
| EPREL Registration Number |
423507
|
Product Data
| Full product code |
872790084053700
|
| Order product name |
TL-E 22W/865 1CT/12
|
| EAN/UPC – Product |
8727900840537
|
| Order code |
928026286570
|
| Numerator – Quantity Per Pack |
1
|
| Numerator – Packs per outer box |
12
|
| Material Nr. (12NC) |
928026286570
|
| Net Weight (Piece) |
0.110 kg
|
| ILCOS Code |
FSC-22/65/1B-E-G10q-29/210
|
