SM060C LED34S/840 PSU W20L120 NOC

Specifications

General Information

Beam angle of light source	110 °
Light source color	840 neutral white
Light source replaceable	No
Number of gear units	1 unit
Driver/power unit/transformer	Power supply unit
Driver included	Yes
Optic type	Beam angle 110°
Luminaire light beam spread	110°
Control interface	–
Connection	Push-in connector 3-pole
Cable	–

Protection class IEC	Safety class I
Glow-wire test	Temperature 650 °C, duration 30 s
Flammability mark	For mounting on normally flammable surfaces
CE mark	CE mark
ENEC mark	–
Warranty period	3 years
Constant light output	No
Number of products on MCB of 16 A type B	24
Photobiological risk	Photobiological risk group 0 @ 200mm to EN62471
EU RoHS compliant	Yes
Unified glare rating CEN	25

Operating and Electrical

Input Voltage	220 to 240 V
Input Frequency	50 or 60 Hz
Initial CLO power consumption	– W
Average CLO power consumption	– W

Inrush current	10.8 A
Inrush time	0.036 ms
Power Factor (Min)	0.9

Controls and Dimming

Dimmable

No

Mechanical and Housing

Housing Material	Steel
Reflector material	Steel
Optic material	Polymethyl methacrylate
Optical cover/lens material	Polymethyl methacrylate
Fixation material	Steel
Optical cover/lens finish	Opal

Overall length	1200 mm
Overall width	200 mm
Overall height	53 mm
Color	White
Dimensions (Height x Width x Depth)	53 x 200 x 1200 mm (2.1 x 7.9 x 47.2 in)

Approval and Application

Ingress protection code

IP20  [ Finger-protected]

Mech. impact protection code

IK03  [ 0.3 J]

Initial Performance (IEC Compliant)

Initial luminous flux (system flux)	3400 lm
Luminous flux tolerance	+/-10%
Initial LED luminaire efficacy	100 lm/W
Init. Corr. Color Temperature	4000 K

Init. Color Rendering Index	>80
Initial chromaticity	SDCM<5
Initial input power	34 W
Power consumption tolerance	+/-27%

Over Time Performance (IEC Compliant)

Control gear failure rate at median useful life 50000 h

0.075 %

Lumen maintenance at median useful life* 50000 h

L65

Application Conditions

Ambient temperature range	+10 to +40 °C
Performance ambient temperature Tq	25 °C

Maximum dim level	Not applicable
Suitable for random switching	Not applicable

Product Data

Full product code	871869606962200
Order product name	SM060C LED34S/840 PSU W20L120 NOC
EAN/UPC – Product	8718696069622
Order code	911401850680

Numerator – Quantity Per Pack	1
Numerator – Packs per outer box	1
Material Nr. (12NC)	911401850680
Net Weight (Piece)	2.750 kg
