Product data
General Information
Cap-Base: GU5.3 [ GU5.3]
EU RoHS compliant: Yes
Nominal Lifetime (Nom): 15000 h
Switching Cycle: 50000X
Technical Type: 5-35W
Light Technical
Color Code: 827 [ CCT of 2700K]
Beam Angle (Nom): 36 °
Luminous Flux (Nom): 345 lm
Luminous Intensity (Nom): 650 cd
Color Designation: Warm White (WW)
Correlated Color Temperature (Nom): 2700 K
Luminous Efficacy (rated) (Nom): 69.00 lm/W
Color Consistency: <6
Color Rendering Index (Nom): 80
LLMF At End Of Nominal Lifetime (Nom): 70 %
Luminous Flux in 90° Cone (Rated): 345 lm
Operating and Electrical
Input Frequency: – Hz
Power (Nom): 5 W
Lamp Current (Nom): 575 mA
Wattage Equivalent: 35 W
Starting Time (Nom): 0.5 s
Warm Up Time to 60% Light (Nom): 0.5 s
Power Factor (Nom): 0.6
Voltage (Nom): 12 V
Temperature
T-Case Maximum (Nom): 82 °C
Controls and Dimming
Dimmable: No
Approval and Application
Energy Efficiency Label (EEL): A+
Suitable For Accent Lighting :Yes
Energy Consumption kWh/1000 h: 6 kWh
Product Data
Full product code: 871869671063000
Order product name: CorePro LED spot ND 5-35W MR16 827 36D
EAN/UPC – Product: 8718696710630
Order code: 929001344302
Numerator – Quantity Per Pack: 1
Numerator – Packs per outer box: 10
Material Nr. (12NC): 929001344302
Net Weight (Piece): 0.045 kg
