08820
PIR sensor fixture
Product information
- casing: plastic
- colour: white
- maximum horizontal operation angle for movement sensor is 360°
- maximum movement detection range is 9m
- maximum verical operational angle for movement sensor is 140°
- movement detection: 0.3…3m/s (1…10km/h)
- possibility of fitting lighting time control from 8s to 8min
- sensitivity adjustment range of 5…2000lx
- setting ambient illumination level at which the equipment operates
Technical parameters
